This GSM modem is a highly flexible plug and play GSM 900 / GSM 1800 / GSM 1900 modem for direct and easy integration RS232, voltage range for the power supply and audio interface make this device perfect solution for system integrators and single user.
Voice, Data/Fax, SMS, DTMF, GPRS, integrated TCP/P stack and other features like the GSM / GPRS modules on this homepage.
GSM modem characteristics
Dual Band or Triband GSM GPRS modem (EGSM 900/1800MHz) / (EGSM 900/1800 / 1900 MHz ) Designed for GPRS, data, fax, SMS and voice applications Fully compliant with ETSI GSM Phase 2+ specifications (Normal MS) General characteristics
Input voltage: 8V-40V Input current: 8mA in idle mode, 150mA in communication GSM 900 @ 12V Input current: 8mA in idle mode, 110mA in communication GSM 1800 @ 12V Temperature range: Operating -20 to +55 degree Celsius; Storage -25 to +70 degree Celsius Overall dimensions: 80mm x 62mm x 31mm / Weight: 200g
Interfaces
RS-232 through D-TYPE 9 pin connector RJ11 voice connector Power supply through Molex 4 pin connector SMA antenna connector Toggle spring SIM holder Red LED Power on Green LED status of GSM / GPRS modulehttp://www.gsm-modem.de
